Pulsar Thermion 3 XT60 Thermal Riflescope
Pulsar Thermion 3 XT60 Thermal Riflescope
The Pulsar Thermion 3 LRF XT60 combines high-resolution thermal imaging, built-in laser rangefinding and an integrated ballistic calculator in a classic 30mm tube design. Featuring a 1280 × 1024 thermal sensor, 60mm F1.0 objective lens and 2–16× magnification, it delivers detailed observation with a broad view of the surrounding ground.
Its traditional profile and compatibility with 30mm mounting rings bring advanced thermal performance to a familiar riflescope format.
Couldn't load pickup availability
Omni Finance powered by
Deposit to Pay £0.00
Loan Amount £0.00
Loan Repayment £0.00
Total Amount Payable £0.00
Rate of Interest 0%
Cost of Loan £0.00
Monthly Payment £0.00
- X (Twitter)
Share

Collapsible content
Further Information
High-resolution thermal imaging
A 12µm thermal sensor and system NETD below 20mK help reveal subtle temperature differences across the scene. The 60mm objective lens provides a thermal detection range of up to 2,800m, while the 50Hz refresh rate supports smooth viewing. Nine colour palettes and three sensitivity amplification levels allow the image to be adapted to different conditions.
A wider view of your surroundings
With a 2× base magnification and a 14.6° horizontal field of view, the XT60 shows 25.7m of ground at 100m. This broad perspective helps maintain awareness of the wider scene, with magnification available up to 16× for closer observation.
High-resolution AMOLED display
The 2560 × 2560 AMOLED display presents a detailed, high-contrast image. A generous 65mm eye relief supports comfortable viewing, while top turret wheel focusing and ergonomic controls keep key adjustments within easy reach.
Integrated rangefinding and ballistics
The built-in laser rangefinder measures distances up to 1,200m. An integrated ballistic calculator brings additional information into the riflescope, with support for the Stream Vision Ballistics app.
Record and connect
Capture photographs and video using the built-in recorder, with recoil-activated video recording available to help preserve key moments. The XT60 includes 128GB of internal storage, dual-band Wi-Fi, Bluetooth and support for Stream Vision 2.
Built for the field
An aluminium alloy housing, IP67 protection and recoil resistance up to 6,000J support use in demanding conditions. Battery life reaches up to 8.5 hours, with USB-C Power Delivery available for external power.
Technical Specification
| Specification | Pulsar Thermion 3 LRF XT60 |
|---|---|
| SKU, without mount | 76590 |
| Thermal sensor resolution | 1280 × 1024 pixels |
| Pixel pitch | 12µm |
| System NETD | <20mK |
| Frame rate | 50Hz |
| Objective lens | 60mm F1.0 |
| Magnification | 2–16× |
| Horizontal field of view | 14.6° |
| Field of view at 100m | 25.7m |
| Thermal detection range | Up to 2,800m / 3,062yd |
| Display type | AMOLED |
| Display resolution | 2560 × 2560 pixels |
| Eye relief | 65mm / 2.6in |
| Dioptre adjustment | −5 to +5 |
| Focusing control | Top turret wheel |
| Mounting compatibility | 30mm rings |
| Built-in laser rangefinder | Yes |
| Rangefinder measurement range | Up to 1,200m / 1,312yd |
| Laser safety class | Class 1 |
| Integrated ballistic calculator | Yes |
| Click value at 100m | 20mm |
| Adjustment range at 100m, horizontal/vertical | 4,000mm / 4,000mm |
| Sensitivity amplification levels | Normal / High / Ultra |
| Colour palettes | 9 |
| Image enhancement | Smoothing filter |
| Calibration modes | Manual / Automatic / Semi-automatic |
| Display-off function | Yes |
| Automatic shut-off | Yes |
| Video and photo recording | Yes |
| Recoil-activated video recording | Yes |
| Internal memory | 128GB |
| USB connection | USB Type-C |
| Wi-Fi bands | 2.4GHz / 5GHz |
| Bluetooth | Yes |
| App support | Stream Vision 2 / Stream Vision Ballistics |
| Battery type | APS5 |
| Battery life | Up to 8.5 hours |
| External power | 5V / 9V USB Type-C Power Delivery |
| Housing material | Aluminium alloy |
| Protection rating | IP67 |
| Maximum recoil resistance | 6,000J |
| Operating temperature | −25°C to +50°C |
| Dimensions, with eyecup | 391 × 96 × 90mm |
| Weight, with battery and without mount | 1.3kg |
Battery life varies with operating conditions and use.
