NocPix Vista H50R LRF Thermal Imaging Monocular
NocPix Vista H50R LRF Thermal Imaging Monocular
SKU: Product code: VISTA H50R
The NocPix Vista H50R Thermal Imaging Monocular features a modern design with a powerful sub 15mK NETD 640x480 thermal imaging sensor, with 50mm lens and integrated laser rangefinder.
With a 2560x2560 Round HD display, NocPix Vista H50R thermal imager provides an immersive observational experience, with top level performance for identifying wildlife species day or night, even in adverse weather conditions.
Couldn't load pickup availability
Omni Finance powered by
Deposit to Pay £0.00
Loan Amount £0.00
Loan Repayment £0.00
Total Amount Payable £0.00
Rate of Interest 0%
Cost of Loan £0.00
Monthly Payment £0.00
- X (Twitter)
Share
Collapsible content
Further Information
The NocPix Vista H50R Thermal Imaging Monocular features a modern design with a powerful sub 15mK NETD 640x480 thermal imaging sensor, with 50mm lens and integrated laser rangefinder.
With a 2560x2560 Round HD display, NocPix Vista H50R thermal imager provides an immersive observational experience, with top level performance for identifying wildlife species day or night, even in adverse weather conditions.
Featuring 4x to 40x variable magnification, NocPix Vista H50R thermal monocular features up to 2600m detection range with 60hz frame rate for a market leading image experience.
Superior Sensor, Precision Image Quality
Our self-developed NETD ≤15mk 640×512 12μm sensor guarantees high image quality and stable performance. Animal silhouettes, anatomy, and behavioral peculiarities become easily distinguishable.

Vision Plus System for Immersive Vision
The AMOLED 1.03inch, 2560×2560 circular display optimises spatial efficiency, delivering vibrant visuals. Boasting an 8mm exit pupil diameter and the Pure Vision Mode, the Vista ensures comfortable and immersive viewing experience.
Integrated Laser Rangefinder
The 2 in 1 integrated in lens rangefinder measures up to 1200m with true optical axis alignment in a lightweight, compact design.

60hz Frame Rate - Seamless Motion Capture
60hz frame rate offers superior fluidity, allowing for the precise capture of moving animals and high speed scenarios. This significant upgrade from 50hz ensures a smoother more accurate visuals.
F0.9 Lens - Enhanced Light Intake
The F0.9 lens is designed to enhance light intake by 20%, significantly improving image brightness and quality compared to traditional F1.0 lenses. This advancement ensures that every detail is vividly clear, making Vista the perfect companion for night observations.
Technical Specification
Specification
- 640x512 Thermal Sensor Resolution
- Sub 15mK NETD sensitivity
- 60hz Super Smooth Frame Rate
- 50mm F0.9 Lens system with 8.8x7 deg field of view
- 4x to 40x magnification
- Up to 2600m detection range
- Integrated Laser Rangefinder up to 1200m
- 5.5 hours run time
- Weight 650 grams
- Dimensions - 194x70x82mm
