Dark 30 Defiance LS 384 PTZ Vehicle Mounted Thermal Imaging Camera

The Dark 30 Defiance LS 384 PTZ is a professional vehicle-mounted thermal imaging camera designed to provide continuous, hands-free thermal observation from a 4x4, pickup, UTV or specialist vehicle. Combining a 384 × 288 thermal sensor, fast 60Hz imaging, a 30mm F1.0 germanium lens and remotely controlled 360° continuous pan, the Defiance LS transforms a vehicle into a powerful mobile thermal surveillance and observation platform.

Ideally suited to fox control, gamekeeping, deer management, wildlife monitoring, farm security, rural surveillance, search and rescue, lost dog groups and professional security applications, the Dark30 Defiance LS allows large areas to be systematically searched for people, animals and other heat sources without constantly operating a handheld thermal imager.

With thermal detection reaching approximately 1150 metres, 1-8x digital zoom, multiple thermal colour palettes and a large 10.1-inch HD display, the Dark 30 Defiance LS 384 PTZ delivers excellent situational awareness both day and night.

384 × 288 Thermal Imaging Performance

At the heart of the Dark 30 Defiance LS is a 384 × 288, 17μm thermal imaging sensor with <40mK NETD thermal sensitivity. Combined with a smooth 60Hz frame rate, it delivers responsive thermal imagery when searching for moving animals, vehicles or people.

The Dark 30 Defiance LT 384 PTZ takes thermal observation out of your hand and puts it on top of your vehicle. Designed as a professional vehicle-mounted thermal imaging system, it provides a continuously controllable 360° view of the surrounding countryside from an elevated position, making it an exceptional tool for fox control, gamekeeping, deer management, wildlife monitoring, farm security and professional mobile surveillance.

At its heart is a 384 × 288 thermal sensor paired with a fast 30mm F1.0 germanium objective lens, smooth 60Hz refresh rate and thermal detection capability extending to approximately 1150 metres. The camera can continuously rotate through 360°, tilt from directly below the unit to 45° above horizontal and be operated remotely from inside the vehicle.

Instead of repeatedly stopping to scan with a handheld thermal monocular, the Dark 30 Defiance LT turns your 4x4, pickup or UTV into a mobile thermal observation platform.

Thermal Imaging Without Leaving the Vehicle

Using a conventional handheld thermal imager from inside a vehicle presents one fundamental problem: thermal radiation does not pass effectively through normal vehicle glass.

The Defiance LT solves this by positioning the thermal sensor externally on the roof of the vehicle. You remain inside while the camera has an unobstructed thermal view of the surrounding landscape. Its elevated mounting position also gives the system an excellent vantage point for scanning across hedges, crops, rough vegetation and undulating ground.

For a gamekeeper or pest controller covering a large estate, this can completely change how ground is searched at night. Drive to an observation point, stop and use the PTZ camera to systematically scan the surrounding fields without continually climbing out of the vehicle.

Continuous 360° Pan, Tilt & Zoom

The PTZ – Pan, Tilt and Zoom – design is what separates the Defiance LT from a conventional fixed thermal camera.

The camera offers continuous 360° horizontal rotation, allowing you to scan completely around the vehicle without reaching for a handheld thermal spotter. Vertical adjustment extends from straight down to 45° above horizontal, providing extensive coverage from a roof-mounted position.

Variable-speed remote control lets you move quickly when searching a large area before slowing the movement for more precise observation once a heat signature has been detected.

A 1-8x digital zoom then allows a detected heat source to be examined more closely.

384 × 288 Thermal Sensor with 60Hz Imaging

The Defiance LT uses a 384 × 288, 17μm thermal detector with <40mK NETD sensitivity, providing dependable heat detection in complete darkness and difficult environmental conditions.

Its fast 60Hz refresh rate is particularly valuable from a moving observation platform, producing smooth imagery when following wildlife or other moving heat sources.

Combined with the 30mm F1.0 germanium lens, the system provides thermal detection at distances of up to approximately 1150 metres / 1250 yards.

For foxing, deer management and gamekeeping, that combination provides the reach required to search substantial areas of farmland before deciding whether something warrants closer investigation.

Large 10.1" HD In-Vehicle Display

There's no eyepiece to peer through with the Defiance LT.

Instead, the system includes a large 10.1-inch 1920 × 1200 LCD monitor, giving you a clear thermal picture from the comfort of the cab. A direct wired connection between the thermal camera and display is designed to provide a low-latency image, keeping camera movement and the displayed thermal picture closely synchronised.

The large display is particularly useful when working with another person. Driver and passenger can both see what's happening rather than having to pass a thermal monocular between them.

For professional security, police and observation teams, it similarly provides a shared thermal picture that can contribute to better situational awareness.

Five Thermal Viewing Modes

Different environments don't always look their best using the same thermal palette.

The Dark 30 Defiance LT provides five thermal colour modes, including White Hot, Black Hot, Rainbow, Magenta and Green Hot, allowing the image to be adapted to the terrain and observation task.

White Hot and Black Hot are ideal for quickly picking out heat signatures while scanning, while the additional palettes provide alternative representations when analysing an area or following a detected subject.

Ideal for Fox Control & Professional Gamekeeping

The Defiance LT is particularly well suited to gamekeepers, fox controllers and professional pest-control operators who spend significant amounts of time working from a 4x4.

Instead of driving a few hundred metres, stopping, getting out and scanning the surrounding fields manually, the roof-mounted thermal camera provides an immediate elevated view around the vehicle.

This makes it possible to systematically search fields, hedgerows, woodland edges, livestock areas and estate boundaries, helping identify heat signatures before deciding on the next course of action.

It can also complement a handheld or rifle-mounted thermal optic: use the Defiance LT as the primary scanning system, then switch to the appropriate observation or shooting optic once quarry has been located and positively identified.

Deer & Wildlife Management

The same capabilities make the Defiance LT a powerful vehicle-mounted wildlife thermal camera.

For deer managers, conservation teams and landowners, the system provides a practical way to locate and observe animals across substantial areas without continually using a handheld thermal imager.

Thermal observation can be particularly valuable around woodland margins and open ground during periods of low light, while the external roof-mounted camera allows wildlife to be observed from inside the vehicle.

It also has applications for livestock monitoring, ecological surveys and locating animals after dark.

Farm, Estate & Rural Security

The Defiance LT isn't limited to hunting applications.

A mobile 360° thermal surveillance camera can be extremely useful for farms, estates, yards and other remote properties where large areas need to be inspected after dark.

Because thermal imaging responds to differences in temperature rather than requiring visible illumination, people and animals can be detected in conditions where a conventional camera may provide very little useful information.

Mounted to a farm pickup or security vehicle, the Defiance LT therefore becomes a powerful tool for farm security, rural crime prevention, perimeter observation and mobile night-time surveillance.

Police, Security & Professional Observation

The ability to remotely search through 360 degrees from an elevated vehicle-mounted position also lends the Defiance LT to specialist professional applications.

Police, security personnel and search teams can use the thermal camera to supplement conventional observation when searching open ground and rural environments after dark.

Rather than requiring an operator to continually hold a thermal device, the Defiance provides a remotely controlled thermal view on a large in-vehicle screen, while its PTZ movement allows areas of interest to be investigated without repositioning the entire vehicle.

Smartphone App Control & Recording

The system can also be controlled through the Dark 30 mobile app for compatible iOS and Android devices, providing another way to operate the PTZ camera.

This becomes particularly useful when the operator isn't sitting directly in front of the main display. For example, the camera can continue acting as an elevated thermal spotter while the user operates elsewhere around the vehicle.

Dark 30 also highlights the ability to use the app when recording footage, broadening the system's usefulness for wildlife monitoring, professional observation and documenting activity in the field.

Temporary or Permanent Vehicle Installation

Not every 4x4 needs a permanently installed thermal camera, so Dark 30 has made the Defiance LT mounting system particularly flexible.

The camera can be attached using suction cups or powerful 100lb / 45.3kg pull magnets for a removable installation, or secured using bolts for a more permanent setup.

This means one camera can potentially be moved between suitable vehicles, while professional users can create a dedicated thermal-equipped gamekeeping, security or observation vehicle with a fixed installation.

The camera itself uses a rugged aluminium housing with IP66 environmental protection and is specified for operation from -20°C to +50°C, helping it withstand the realities of year-round outdoor work.

A Mobile Thermal Observation Platform

For users who routinely work from a vehicle, the Dark 30 Defiance LT 384 PTZ offers a fundamentally different approach to thermal observation.

Rather than treating thermal as something you pick up every few minutes to scan the same ground, the Defiance becomes part of the vehicle itself – ready to search the surrounding landscape whenever required.

The combination of a 384 thermal sensor, 1150m detection capability, 360° PTZ control, 10.1" HD display, smartphone operation and versatile vehicle mounting makes it an extremely capable system for fox control, gamekeeping, deer management, wildlife observation, farm security, police work and professional mobile thermal surveillance.

Key Specifications

• 384 × 288 thermal imaging sensor
• 17μm pixel pitch
• <40mK NETD thermal sensitivity
• 60Hz frame rate
• 8-14μm spectral range
• 30mm F1.0 germanium objective lens
• Detection range up to 1150m
• 1-8x digital zoom
• Continuous 360° pan
• Tilt from directly downwards to 45° above horizontal
• Five thermal colour palettes
• 10.1-inch LCD display
• 1920 × 1200 display resolution
• Low-latency HDMI camera-to-screen connection
• Variable-speed remote control
• Dark 30 App control
• iOS & Android compatibility
• Sleep Mode
• Return to Home function
• TF card slot
• 2 × HDMI ports
• 2 × DC ports
• Aluminium construction
• IP66 environmental protection
• 12V DC vehicle power
• Operating temperature: -20°C to +50°C
• Dimensions: 169 × 195 × 198mm
• Weight: approximately 2.68kg
• Suction mounting option
• 100lb magnetic mounting option
• Permanent bolt mounting option

Ideal Applications

• Fox control and professional pest management
• Gamekeeping
• Deer management and wildlife management
• Wildlife observation and monitoring
• Farm and livestock monitoring
• Estate management
• Rural security
• Farm security and rural crime prevention
• Perimeter surveillance
• Mobile thermal surveillance
• Police and law-enforcement observation
• Search operations
• Security patrol vehicles
• 4x4 and UTV thermal imaging
• Professional night-time observation
